SKU#(400) Be the First to Review this Item

KOBOLD  SMF-5101

FLOW / METERS
WEATHERPROOF IP65

$274.00     Availability: 7 Days
 Info/Quote Request
 Shipping Rates
 Volume discount




KOBOLD SMF-5101
  • Overview
  • Benefits
  • Specs
  • Documents

KOBOLD SMF High Pressure - All-Metal Flowmeter and Switch. Vertical, Flow Bottom to Top. Direct Reading Scales for Water or Air. 5% Accuracy, 3600/5000 PSI max pressure. Brass or Stainless Steel Versions. IP65.

Part# with Options:        SMF-5101
Price with Options:        274.00

Options:

Model
(1) Model for KOBOLD SMO
Range
(2) GPM Range for KOBOLD SMF
Scale
(3) Scale for KOBOLD SMO
Larger Fittings
(4) Larger Fittings for KOBOLD SMO
Conduit Fitting
(5) Conduit Fitting for KOBOLD SMO
Extra Contact
(6) Extra Contact for KOBOLD SMO
SPDT Upgrade
(7) SPDT Upgrade for KOBOLD SMO

  Availability 7 Days  ]

Description

The SM Series fl owmeters can be ordered with set point switches to actuate at a specifi c fl ow rate. The switches are mounted externally in a protective housing and are actuated by a magnet within the fl oat. This same magnet can also be used to couple to an external fl ow indicator, allowing for reading of the fl ow rate without requiring visibility of the fl oat. The SM offers all of the benefi ts inherent in an all-metal design, such as high pressure and shock resistance. They are designed to handle fl ow rates much larger than their stated maximum range without damage. At excessive fl ow rates, however, there is a larger pressure drop.

Applications
  • Lubrication Circuits
  • Paper-making Machines
  • Machine Tools
  • Glass-melting Tanks
  • Cooling Circuits
  • Welding Machines
  • Induction Furnaces
  • Pumps

Technical Details
Accuracy: 5% of Full Scale
Media:Liquids or Gases
Installation
SMV:Vertical, Flow Bottom to Top
SMO:Vertical, Flow Top to Bottom
SMW:Horizontal, Flow Left to Right or Flow Right to Left
SMF:Vertical, Flow Bottom to Top
Measuring Principle
SMV:Float and Cylindrical Control Tube
SMO, SMW, SMF:Float Return Spring and Cylindrical Control Tube
Mode of Operation:Dependent on Flow (not Pressure)
Max. Temperature:212 F (PP Float 160 F)
Max Pressure
Brass Units:3600 PSIG
Stainless Steel Units:5000 PSIG
Units with PP Floats:230 PSIG
Materials of Construction
Body:Ni-plated Brass or 304 Stainless Steel
Slotted Nozzle:Ni-plated Brass or Stainless Steel
Float:Ni-plated Brass, Hard Anodized Aluminum, Polypropylene, or SS
Spring:301 Stainless Steel
Fittings:Ni-plated Brass, or 304 Stainless Steel
Seals Brass Units:NBR
Seals SS Units:FKM
Switch Housing:Plastic
Pointer Indication:Ni-plated Brass, Polycarbonate Lens (Magnetically Operated)
Reed Contact (cCSAus) N/O & SPDT:max. 230 Vdc/0.26A/60W 60 Vdc/1A/60W
max. 240 Vac/0.42A/100W 100 Vac/1A/100W
Electrical Contact Protection:IP65
Side Indicator Protection:IP54
